JRF series coal-fired hot air stove
JRF series coal-fired hot air stove
Description
This furnace integrates combustion and heat exchange, and uses a new indirect heating technology to exchange heat in the high-temperature parts of the furnace body. Smoke and air flow independently, and heating is absolutely pollution-free. The thermal efficiency is as high as (60-75 ° C), with fast heating, small volume, convenient installation, reliable use, and low price (compared to a one ton boiler, this heating system is only half the price of a boiler heating system). Equipment Process
High temperature resistance measures have been taken, which greatly extends its lifespan compared to tubular hot air stoves. The longitudinal flushing of heat dissipation fins and negative pressure smoke exhaust method are used, and the heat exchange area does not accumulate dust, requiring no cleaning, and the thermal performance is stable. Various types of coal or firewood can be used as fuel, and equipped with a secondary air inlet device for complete combustion. The various technologies of this furnace have reached the domestic level.
| Model/Parameters | Output heat × 105kcal/h | Output air volume (m3/h) | Hot air temperature (℃) | Coal consumption (kg/h) | Model of smoke induced draft fan |
| JRF4-2.5 | 1.045 | 1500-560 | 60-200 | 10-12 | Cooking with a blower 80-100W |
| JRF4-4 | 1.672 | 3500-930 | 60-200 | 14-17 | Cooking with a blower 200-300W |
| JRF4-8 | 3.344 | 5600-1480 | 60-200 | 18-24 | Y5-47 No2.8C 1.1KW |
| JRF5-15 | 6.270 | 12000-2160 | 60-300 | 40-45 | Y5-47No 4C 2.2kw |
| JRF5-30 | 12.54 | 25000-4330 | 60-300 | 80-85 | Y5-47 No4C 3kw |
| JRF5-40 | 16.72 | 28000-5600 | 60-300 | 115-125 | Y5-47 No4C 3kw |
| JRF5-60 | 25.08 | 45000-8600 | 60-300 | 160-170 | Y5-47 No4C 3kw |
| JRF6-80 | 33.44 | 83000-12500 | 60-300 | 240-250 | GY2-1 11KW |
| JRF6-160 | 66.88 | 134400-23000 | 60-300 | 480-490 | GY4-1 18.5kw |
| JRF6-200 | 83.60 | 170000-28000 | 60-300 | 600-620 | GY4-1 18.5kw |
