LDP series fluidized bed coating machine
LDP series fluidized bed coating machine
Description
Bottom jet fluidization, material has strict operating trajectory, thus obtaining uniform and continuous coating film
Coating with powder particles, pill masking, moisture resistance, oxidation resistance, waterproofing, heat resistance, color isolation, etc
No loss of coating materials and low production costs
The route of fog particles to materials is short, so there is no danger of "spray drying"
Cylindrical acceleration container or inverted cone deceleration design, feasible for particle, large particle, small particle, and micro pellet coating
Excellent material dispersion and no adhesion phenomenon
Fluidized bed coating machine is a new type of particle coating equipment that organically combines fluidization coating technology and spray technology. It is widely used for film slow and controlled release, skeleton slow and controlled release capsules, pill coating, particle and powder coating.
| Specification Item | 5 | 15 | 30 | 60 | 120 | 200 | 300 | |||
| Capacity | Kg/batch | 4 ～ 6 | 10 ～ 20 | 25 ～ 40 | 40 ～ 80 | 80 ～ 150 | 150 ～ 250 | By URS | ||
| Volume of container | L | 15 | 50 | 100 | 220 | 360 | 650 | |||
| Power of fan | Kw | 4 | 5.5 | 7.5 | 15 | 18.5 | 22 | |||
Mpa | 0.6 | |||||||||
compressed air | pressure consumption | m 3 /min | 0.4 | 0.6 | 0.9 | 1.3 | 1.8 | 2.4 | ||
| steam | pressure | Mpa | 0.4-0.6 | |||||||
| consumption | Kg/h | 9kw | 64 | 85 | 181 | 250 | 330 | |||
| Size of installation for reference | H 1 (mm) | 2600 | 2850 | 3150 | 3250 | 3500 | 3800 | |||
| H 2 (mm) | 340 | 490 | 590 | 790 | 890 | |||||
| H 3 (mm) | 2630 | 2930 | 3020 | 3280 | 3580 | |||||
| B 1 (mm) | 1010 | 1160 | 1460 | 1660 | 2060 | 2260 | ||||
| B 2 (mm) | 1560 | 1860 | 2460 | 2860 | 3660 | 4060 | ||||
| φ 1 (mm) | 550 | 700 | 1000 | 1200 | 1600 | 1800 | ||||
| φ 2 (mm) | 180 | 250 | 250 | 280 | 280 | 315 | ||||
| L(mm) | 850 | 1550 | 1700 | 1800 | 2000 | 2100 | ||||
